Geberit Omega 12 built-in cistern with Combifix installation module for 82 cm wall hung wc

Geberit Combix module with Omega cistern 12 cm for wall hung toilet, 82 cm.

Geberit Combifix with Omega 12 Cassette is the complete solution for bathroom systems: designed for masonry construction, recessed installation, in front of the wall or under a window, in brick or concrete.

The Geberit Combifix Omega 12 installation module provides maximum long-lasting performance and ease of assembly on site. In fact, all Geberit modules are assembled in the factory so that they can be quickly installed on the construction site and connected to the water supply and drain pipes with the utmost ease. An advantage that also takes into account possible changes and future renovations. Omega 12 cisterns are reliable as they are leak tested and come with a 25-year spare parts availability guarantee.

The Geberit Combifix module is complete with accessories, such as soundproofing mat, drain bend, stop cock and mounting hardware.

Features:

- Two-quantity rinse

- Powder coated mounting frame

- Mounting frame coated with four fixing flanges

- Technical curve mountable without tools

- Built-in flush cistern with front or top operation

- Built-in cistern insulated against condensation

- With the default setting possibility of immediate additional rinse

- Assembly and maintenance work on the concealed cistern without tools •

- Water connection at the top left

- Site protection with shortenable inspection opening, suitable for flush-mounted control plates

- Equipped with lining tube for water connection of Geberit AquaClean bidet toilet

- With the possibility of fixing for electrical connection

Supplied material

- R 1/2 water connection, MF compatible, with integrated shut-off valve and knob

- Technical curve in PE-HD, ø 90 mm

- 2 M12 threaded rods

- Fixing material

- Site protection with inspection opening

- Toilet connection set, ø 90 mm

- 2 protective caps

- Decoupling set
