KLOVER BELVEDERE 28 PELLET STOVE WATER + AIR + DHW KIT + TANGENTIAL FAN
Nominal Thermal Power 23.7 kW (20.3 kW transferred to the water of the heating system; 3.4 kW returned to the environment by forced ventilation and radiation)
Ideal for heating an area of about 220 m 2 with a height of 2.7 m
The BELVEDERE 28 offers the highest performance among Klover pellet stoves. A real fire engine that, with its very high combustion efficiency of 94.8% at maximum power (95.5% at reduced power) and very low CO emissions, is capable of producing water for heating even homes. of important dimensions, up to 220 square meters. A unique article, which synthesizes aesthetics and functionality at the highest levels. Complete with domestic hot water production kit , the stove is also able to produce the hot water needed for domestic use. Furthermore, thanks to the front tangential fan included in this version, it is possible to heat the room in which the stove is installed immediately and without subtracting heat from the heating system of the house; an added value that few other machines of this type on the market possess.
NEW DESIGN
BELVEDERE 28 has a linear design and well rounded edges that make it perfectly adaptable to both classic and modern environments. Its shapes are simple and clean but a game of contrasts of colors and different materials, return a rich but always harmonious image. The basic color that Klover offers in 6 different variants is contrasted by the contrasts on all the details of the front: the upper grille, the splendid double central glass with a "cold" door opening handle and the very particular lower ash drawer, have well-defined contours by the satin-chrome frames. The front and upper cladding is made of refined majolica which, in addition to giving it a pleasant and quality finish, offers the great advantage of accumulating heat and releasing it gradually. The side cladding is instead in painted steel . The elegance of the BELVEDERE 28 , in the version proposed here, is even more enhanced by the glossy ivory color . And then, the sight of the fire through the glass, on the one hand transmits even more the image of the power that this stove can deliver, on the other it gives a pleasant sensation of warm relaxation!
GUARANTEED SAVINGS AND HIGH COMFORT
The BELVEDERE 28 pellet stove by Klover is of the hydro type , that is, it heats the water and, being connected to the heating system of the house, is able to give heat to the whole house . It is an article that contains the best technologies and maximum performance among stoves powered only with pellets. An efficient, strong, powerful and high quality item, with a sturdy and well insulated body.
The standard domestic hot water kit allows to obtain an efficient production of domestic hot water.
Furthermore, thanks to the front tangential fan of this version, the surrounding environment can be heated immediately without removing heat from the heating system of the house. The activation and regulation of the fan are manual.
The BELVEDERE 28 is complete with the boiler control system which puts any combined gas boiler in stand-by when the stove circulator starts, so there will be no two boilers operating on the same circuit. However, the combined boiler will always be usable for the production of domestic hot water. But it is also complete with the 3-way valve control on the sanitary circuit which closes automatically if it is not able to satisfy a significant demand for sanitary water: if the valve is at rest, the water passes from the gas boiler, at the moment in when the temperature of the thermo stove is sufficient, the three-way valve is powered and therefore closes the sanitary circuit of the gas boiler and opens that of the pellet stove.
Furthermore, in this version, the thermo stove is equipped with the sanitary function which, if set, allows all the heat produced to be transferred to the sanitary water.
The door has a highly resistant double ceramic glass up to a temperature of 850 ° C. The combustion chamber is equipped with hermetic seals in stainless steel which, guaranteeing absolute insulation, allow a particularly efficient combustion and offer the maximum possible safety. Maximum insulation has also been achieved in the cast iron brazier and in its gasket so that the incrustations of pellet residues are a much less frequent phenomenon. The wirings covered in anti-wear and anti-cut glass fiber have a particular resistance to high temperatures, practically eternal!
The BELVEDERE 28 is equipped with integrated safety sensors that offer constant control over the entire system. The pellet loading system is treated with a total chrome plating ( chrome protected ) in all its parts in order to always be protected from any humidity present in the fuel.
The optimization of electricity consumption is supported by the high efficiency electronic circulator . Thanks to a latest generation electronic board , the operation of the boiler is totally automatic but above all particularly efficient and safe. The control possibilities are manifold. The BELVEDERE 28 pellet stove is equipped with an automatic weekly chronothermostat with touch display that allows you to set up to four daily operating periods, even different for each day of the week, and also with a practical remote control to remotely manage the most important functions; however, it is possible to associate a remote control panel or a room thermostat (to be purchased separately) to control it from a room other than the one where it is located; in this case, however, it will not be possible to guarantee the production of domestic hot water. The stove even offers the possibility of being remotely controlled via a WI-FI system using a WI-FI module (optional) and the MyKlover app to download on a smartphone or tablet.
The consumption of pellets is always very low; the BELVEDERE 28 offers great power and very high efficiency , up to 95.5%.
In energy class A ++ thanks to its efficiency and emissions parameters, it is a product compliant with the Ecodesign 2022 regulation and can take advantage of the tax incentives of the Thermal Account 2.0 or the tax deductions of 50 and 65% .
GREAT MODULARITY OF INSTALLATION AND USE
The BELVEDERE 28 pellet stove by Klover has a remarkable versatility of installation and very easy maintenance. Its dimensions allow it to easily find a suitable location in the environment that hosts it; the standard hydraulic components further facilitate connection operations to both heating and sanitary systems. For maintenance, the side scrapers for cleaning are already present.
DIMENSIONS
Width: 660 mm - Height: 1310 mm - Depth: 650 mm
Weight: 280 kg
WARRANTY
The warranty is the official Klover one and has a duration of 24 months.
