Beretta CIAO X 30C condensing - 17,2 l/min.
Natural gas boiler - Convertible to LPG and propane air
24 kW – Ideal for heating up to 150 m2 with an average height of 2.7 m
Code 20197876
THE BOILER
Heir to one of the best-selling boilers ever, the CIAO by Beretta , the new CIAO X takes up the best of this heritage and evolves by looking to the future between energy saving and technological innovation .
Of its predecessors, the Beretta CIAO X condensing boiler certainly maintains the reliability , simplicity of use and great versatility . However, it is renewed and improved, both inside and out: inside, thanks to its new high performance steel condensing exchanger and the brand new sanitary exchanger with oversized plates ; outside, in the clean and modern design and in the user interface, a technological but simple and intuitive touch panel to use.
The CIAO X condensing boiler by Beretta therefore has a heart of steel: its stainless steel condensing exchanger offers unparalleled performance, up to 93% average efficiency Erp. The exchanger consists of a single coil wrapped in high-section stainless steel which guarantees greater efficiency and longer-lasting cleaning because it is highly resistant to the corrosion typical of the acid condensates of condensing boilers. The flow rate remains constant and clogging phenomena are limited thanks to the geometry of the exchanger; the exchanger is also accessible from the front for maintenance operations thanks to a system of guides which allows easy disassembly and reassembly.
Even the heat exchanger on the domestic hot water circuit has been optimized with high efficiency plates to allow, through the Pre -heating function, to have domestic hot water quickly at a stable temperature .
The high-efficiency modulating circulation pump (EEI ≤ 0.2) of the CIAO X boiler allows for improved performance and lower electricity consumption as well as higher durability of the components. The HELLO X it differs from other condensing boilers for its greater efficiency for the same fuel used. In fact, the modulation range of this line of boilers reaches up to 1:8 of the nominal power: when the environment is heated, the boiler is able to reduce the flame up to one eighth of the maximum to keep the temperature constant, in this way not only does it not turn off but it guarantees greater efficiency and silence , decreases in temperature changes and electricity consumption . It is therefore possible to avoid continuous switching on and off and also keep expenses under control.
The Beretta CIAO X boiler also has a modern touchpad user interface : the command, very intuitive, has a backlit LCD display which communicates to the user via representative icons ; seven surrounding function keys allow access to all the settings and parameters of the boiler by activating a buzzer to confirm each operation. From the display it is possible to program weekly switching on and off of the boiler and to activate or deactivate the Pre-heating function on the DHW circuit.
The Beretta CIAO X condensing boiler is designed for both indoor and outdoor and built-in installation: thanks to its IPX5D degree of protection (protection from water jets and dust), the compact dimensions that allow Also placed in a kitchen wall unit, extremely silent , this boiler can easily adapt to different installation requirements and integrate into new building projects such as redevelopment . The hydraulic unit with DIN connections also makes it ideal for replacements.
The boiler is also designed for coupling with the latest generation chronothermostats such as HiComfort T100 or HiComfort T100 Wi-Fi by Beretta (which can be purchased separately) which make it manageable wherever you are simply using a smartphone or tablet.
As far as emissions into the atmosphere are concerned, the burner of the CIAO X is pre -mixed and reaches the NOx6 level, allowing the levels of burnt gases to be kept low at all times.
The HELLO X is a HYDROGEN READY boiler, i.e. it is set up for operation with gas and hydrogen mixtures up to 20% which makes it possible to reduce final consumption with an eye always attentive to respect for the environment.
The boiler is standard with methane operation but can be converted to LPG or propane air operation by requesting the conversion to the Beretta CAT in the first ignition phase.
The boiler has the flue gas flange with quick-tightening safety collar installed as standard, making installation operations simpler and faster.
GUARANTEED SAVINGS AND HIGH COMFORT Thanks to its innovative technological characteristics, the CIAO X fits admirably into the family of Beretta boilers attentive to consumption management combined with high efficiency and low emissions and therefore respect for the environment, reaching an A+ energy class if combined with a latest generation control such as HiComfortT100 or HiComfortT100 Wi- Fi by Beretta (optional).
DIMENSIONS
Height: 700mm - Width: 400mm - Depth: 275mm
Weight: 30kg.
WARRANTY
The guarantee is the official Beretta one and has a duration of 24 months .
