Cadel Atena Plus 12 pellet stove with ducted air 12 kW - WiFi TITANIUM METAL
Thermal power 12 kW
Ideal for heating rooms up to 130 m2 with an average height of 2.7 m
The Cadel Atena Plus 12 is a powerful, modern, and highly efficient ducted air pellet stove, designed to heat even large spaces with low energy consumption. Thanks to its sealed chamber , it offers comfort and high performance in complete safety. Its elegant design integrates seamlessly into any home, while smart management with Wi-Fi and Bluetooth makes it simple and immediate to use. A versatile, reliable stove designed to maximize daily well-being.
This is a ducted hot air stove that distributes heat not only throughout the room in which it is installed, but also to other rooms thanks to its dual ducting with independent motors: all duct fans can be controlled independently. Energy efficiency class A+ and environmental rating 5 stars.
DESIGN
The Cadel Atena Plus 12 stove stands out not only for its performance but also for its carefully considered design , which combines elegance, functionality, and harmony with the home environment. The external cladding with a TITANIUM-colored metal finish allows the stove to be inserted into contemporary or classic settings and personalize the environment with style. One of the most refined components is the cast iron door with panoramic ceramic glass : in addition to ensuring sturdiness and durability, it offers a wide view of the flame , transforming the stove into a true "atmospheric element". The use of cast iron also extends to the top and brazier , lending solidity and a touch of superior aesthetic quality.
TECHNOLOGY, EFFICIENCY AND COMFORT OF DUCTED PELLET STOVES
Thermally, the Atena Plus 12 delivers a nominal power of 12 kW and a rated firebox output of around 13.5 kW. Efficiency reaches approximately 90% at nominal power, rising to 93.5% in reduced mode. The pellet hopper has a 23 kg capacity, allowing for up to 26-27 hours of burn time in optimal conditions.
The stove is sealed chamber , meaning it draws combustion air from the outside and not from the room in which it is located: this increases safety, efficiency, and reduces ambient air loss. The flue outlet can be either rear or top (optional) and has a diameter of 80 mm. The combustion air intake is Ø 60 mm. A Ø 80 mm outlet is provided for ducting hot air.
The stove is equipped with an electronic control interface that allows the user to easily and comprehensively set and monitor operating parameters. The front panel allows you to view the operating status, room temperature, any error codes, and select preset programs. It can be connected to an external thermostat , including a remote control (optional) , for more efficient and personalized comfort. Some configurable functions include:
-
Daily and weekly programming : You can set automatic on/off time slots for each day of the week. This allows you to have a warm home when you return home or keep the temperature low when it's not needed.
-
Power and ducted ventilation adjustment : thanks to the "ducting" function with independent motors, the stove allows you to adjust the flow of hot air distributed to the various rooms. The ducted fans with two independent motors allow you to distribute heat not only in the main room but also in secondary rooms, selecting whether to convey more or less air through the ducts.
-
Comfort Mode (silent mode) : When set to "Comfort" mode, the stove temporarily reduces or suspends forced ventilation, while still maintaining the heat emitted through radiation or natural convection. This is especially useful at night or in environments where you want peace and quiet without active fans.
A key feature of CADEL's Atena Plus 12 pellet stoves is the standard Easy Connect Wi-Fi panel , which allows for remote management via smartphone, tablet, or PC. All you need is a Wi-Fi connection and the CADEL Easy Connect Plus app to access the stove's control and management panel from anywhere, even from multiple devices. Thanks to the standard Bluetooth feature , you can also connect your smartphone to the stove when nearby, without the need for a Wi-Fi signal. With Easy Connect Plus, you can turn the stove on and off, monitor and manage the room temperature, set the timer and chronothermostat, and monitor the generator's status and consumption.
The Atena Plus 12 stove is classified in energy class A+, 5-star environmental class , and other certifications thanks to its particularly low emissions. This means that the user benefits not only from efficient heating, but also from an appliance that complies with the most stringent environmental regulations, an increasingly important aspect today.
NB: further specifications and details are contained in the attached technical data sheet.
DIMENSIONS
Width 58 cm_Height 114 cm_Depth 58 cm
Weight 152 kg
Flue pipe Ø 80 mm
WARRANTY
The warranty is the official Cadel one and lasts 2 years.
