Samsung Cassetta360 24000 BTU R32 Inverter A++ Air ConditionerThe air conditioner kit is equipped with the following indoor units:
- 1 x 24000 BTU - Ideal for rooms from 80 to 100 sqm with an average height of 2.7 m
The Samsung Cassetta360 is the indoor unit designed for better air conditioning in terms of performance and comfort. Innovative, elegant, perfect even for the most sophisticated contexts , this unit ensures a 360° air flow with optimal distribution, avoiding the creation of zones with different temperatures.
The Samsung Cassetta360 offers a choice of design installation, it can be installed exposed or in a false ceiling like classic cassettes. This makes it a very sought-after cassette even in environments and applications where high architectural standards are required.
DESIGN AND AIR FILTRATION SYSTEM
The Samsung Cassetta360 air conditioner has a modern and sophisticated design, beautiful to look at because it combines the peculiarity of the circular shape with the honeycomb texture of the air diffusion grille. Aesthetically incredible, it offers the great advantage of not taking up space on the walls for installation, furthermore the possibility of positioning the units in central points of the rooms allows for perfect and homogeneous diffusion of the air conditioned. Unlike traditional cassette units, which distribute the air using only 4 guide fins, the Cassetta360 offers uniform distribution of the air in the room avoiding the creation of zones with different temperatures; in fact, the presence of fins or diffusers in general constitutes a loss of load for the fan of the units, this particular configuration instead, allows for reducing losses to a minimum by fully exploiting the air flow provided by the fan. The cassette includes the mandatory circular panel cod. PC4NUNMAN.
The antibacterial filter of the Samsung Cassetta360 is designed to reduce bacteria, allergens and impurities in the air, improving the quality of the environment. Thanks to its advanced technology, it ensures cleaner and healthier air, ideal for daily well-being. The filter is easy to remove and reinsert to facilitate periodic cleaning operations; from the display on the panel it is possible to monitor both the level of air purification and the cleaning status of the filters.
Furthermore, on the side of the box there is a pre-cut hole which can be used to connect a duct for the inlet of fresh air .
TECHNOLOGY AND COMFORT OF THE SAMSUNG CASSETTE360
The Samsung Cassetta360 air conditioner is a concentration of technology and comfort. Samsung is a guarantee of efficiency, the performance of these units is supported by Inverter technology which modulates the power to offer high quality and low consumption. The Cassetta360, for example, is equipped with a fan with an Inverter motor. The air flow is regulated without the use of fins: a Booster Fan modifies the pressure inside a cavity that diverts the direction of the air outlet. The direction of the air flow can be managed in 3 independent sectors. Depending on the installation height, it is possible to increase the air flow to have optimal coverage up to a maximum height of 4.6 m .
The unit features an elegant panel and an intuitive LED display. You can direct the airflow as you like, choosing between three settings, including horizontal and vertical, and control the direction of the airflow in individual zones. The display is also equipped with a warning system that helps the user, through the different colors and shapes of the LED lights, to monitor the filter cleaning status and any errors.
360° air flow without distribution fins that create that pleasant coanda effect typical of the best air conditioners, with pressure drops reduced to a minimum, to obtain maximum comfort of use. The condensate drainage pump is incorporated.
It can be managed via the Samsung Advance wired control code MWR-WG00KN included which allows access to numerous settings and control functions, as well as the ability to connect and manage multiple internal units with a single command! It can also be managed conveniently from your smartphone via WiFi, by purchasing the optional WiFi kit code MIM-H04EN separately. The Samsung Cassetta360 uses the Nasa communication protocol which integrates the operation of the air conditioning units, optimising the entire system.
WARRANTY
The warranty is the official Samsung one and lasts 2 years.
Samsung MWR-WG01KN Advance Wired Remote Control for Samsung Air Conditioners
The Samsung Advance wired control model MWR-WG00KN allows you to customise and programme the air conditioner in order to best manage the environmental comfort of the rooms where it is installed.
Compatible with models from the Samsung MONO, MULTI, CAC, EHS lines.
Redesigned compared to previous models, it has a square shape with rounded edges and is made of white glass with a color display; it will fit elegantly and discreetly into any environment.
It is a wired control and connects to the internal unit using the appropriate cables.
Some settable modes and features:
-
Operating modes: cooling, heating, dehumidification, ventilation;
-
Temperature and fan speed control;
-
Weekly programming and time setting;
-
Advanced features such as silent, night and energy saving modes;
-
Air purification function (Purify);
-
Error handling and reporting codes;
-
Integrated ambient temperature sensor.
-
Audible and visual alarm in case of refrigerant leak.
Further functions can be viewed in the user manual supplied with the product.
WARRANTY
The warranty is the official Samsung one and lasts 2 years.
THE EXTERNAL UNIT
The external unit for air conditioners of the SAMSUNG commercial line, with Inverter technology and Heat Pump is the beating heart of the air conditioner.
The external units for commercial air conditioners are used for the Monosplit combinations of the Samsung CAC range and allow you to connect a single internal unit or, for the Twin, Triple and Quadri combinations, to connect multiple internal units using the appropriate Connection Joints.
GUARANTEED SAVINGS
The SAMSUNG outdoor unit always provides power proportionate to the real air conditioning needs of the environment in which its single indoor unit or indoor units are located. It offers high performance and great comfort both when using the air conditioner in cooling and heating. Thanks to the Inverter system, the outdoor unit allows for high energy savings and particular attention to the environment, in addition to achieving the highest Energy Classes by reducing waste to a minimum .
The Inverter Twin Rotary BLDC compressor is equipped with two rotors that can rotate in opposite directions, thus reducing the noise and vibration of the system. The Heat Pump allows you to use the air conditioner all year round, both in summer to cool and in winter to heat.
For operation it uses R32 gas which has a very low environmental impact, Samsung always focuses on environmental protection.
The extended temperature limits allow the machine to operate in cooling mode from -15°C to 50°C external and in heating mode from -20°C to 24°C.
The pipe can be installed in 4 different directions making the installation extremely flexible. Particularly resistant to weather and atmospheric agents, it can be fixed both in a suspended position and resting on the floor thanks to the supports that can be purchased separately.
WARRANTY
The warranty is the official Samsung one and lasts 2 years.
WHITE CIRCULAR PANEL FOR SAMSUNG CASSETTE 360 INTERNAL UNIT
The circular panel presented here is used together with the Internal Unit of the SAMSUNG Cassette360 Air Conditioner.
It allows the edges of the cistern to be joined in the installation recess and covers all defects and imperfections in the recess.
It aesthetically completes the box, giving it even more elegance.
DIMENSIONS
Diameter: 947 mm.
WARRANTY
The warranty is the official Samsung Italy one and lasts 2 years .
