Clivet Aura CFFAC 10 CC2 R3 fan coil unit with casing 7.15 - 6.75 kW

Clivet Aura CFFAC 10 CC2 R3 fan coil

The Aura fan coil unit has a heating power of 7.15 kW and a cooling power of 6.75 kW.

Heating function: ideal for units of approximately 65 m2 with an average calculated height of 2.7 m

Cooling function: ideal for units of approximately 70 m2 with an average calculated height of 2.7 m

The new Clivet Aura Fancoil fits perfectly into a wide range of configurability to make it suitable for domestic and tertiary environments and, thanks to the available control systems, it is compatible with single, group or centralised management.

The aesthetics of the Aura fan coil unit was designed by Italian designers and fits harmoniously into modern and elegant domestic or tertiary environments. In fact, thanks to the reduced thickness of 200 mm, it can be inserted even in the narrowest environments without neglecting the availability of space, thus reducing clutter.

Aura fan coils are available in a wide variety of configurations. The CFFAC 10 CC2 R3 model with 2-pipe AC motor is a visible casing that can be installed vertically and horizontally, both on the wall and on the ceiling. It is composed of a copper/aluminium exchanger , with hydrophilic coating, an electrical panel, L-shaped basin, 3/4'' water connections, condensate drain (diameter 18.5 mm), centrifugal fan, washable filter (class G2), galvanized sheet metal casing. The connections of the 'water can be moved to the opposite side of the unit, simply by rotating the heat exchanger. The Aura CFFAC fan coil unit is equipped with a terminal block that allows compatibility with the optional KJRP-86R user interface that can be installed either on the machine or wall mounted; 3-speed ventilation control; ELFOcontrol3 and BMS Modbus compatibility; Silent operation and easy cleaning.

The unit is completed by the wired interface to be purchased separately (KJRP-86R). The touch screen and backlit allow the best usability for the user, both in installation on the machine or remotely. The wired user interface can be installed on board the machine, on both sides, or remotely mounted on the wall thanks to the KJRP-86 wall installation box (optional).

DIMENSIONS

Length: mm. 1360 – Height: mm. 595 - Depth: mm. 200.

OPTIONAL ACCESSORIES

-Electromechanical thermostat on board the machine (KJRP-86R)

-Feet kit

WARRANTY

The guarantee is the Official Clivet one and lasts 24 months.
