IVAR MAGNETIC DIRTSTOP EASY 3/4 F x 3/4 M UNDER-BOILER FOR CONDENSING BOILER
Code 520360
The dirt separator is a device used in heating systems with condensing boilers and performs the important function of protecting the boiler. It is installed on the return of the heating circuit before the water re-enters the boiler and retains the impurities present in the circuit which would otherwise damage the exchanger and the other components of the boiler. In addition to prolonging the life of the boiler, it considerably increases the efficiency of the heating system, improves the efficiency of the whole system, helps keep the valves and radiator holders clean (the use of the dirt separator in association with the valves is recommended thermostatic). The use of the dirt separator therefore makes it possible to obtain considerable savings also on gas consumption because the boiler must always heat clean water. It is recommended to install the dirt separator already in the system activation phase or in any case at the same time as the replacement of an old boiler with a new condensing one.
Dirtstop Easy by IVAR is a magnetic, adjustable, universal dirt separator. Prepared for installation under wall boilers on both horizontal and vertical pipes, its particularity is the possibility of being installed in different positions . Its dimensions are extremely small so as to easily find accommodation even in the smallest spaces. An absolutely versatile item with quick and easy installation.
• Can be installed in any position, as removed from the box.
• Internal separation chamber which guarantees perfect filtration in all installation positions.
• Extremely compact, it can be easily installed under the boiler even in small spaces.
• Maintenance even when the system is running: it can be cleaned without being disassembled.
• Large decantation chamber, complete with ball valve for discharging impurities, which ensures quick and easy cleaning.
• Made of IXEF®, a technopolymer with extraordinary mechanical properties, comparable to those of brass.
The Dirtstop EASY dirt separator retains the impurities present in the closed circuit of the heating system. The presence of the internal separation chamber forces the water to pass through the filter in any installation position, always guaranteeing maximum filtering action. The powerful neodymium magnet also retains impurities of ferrous origin, safeguarding the heat exchanger and the heat generator pump. Install Dirtstop® EASY on the return pipe of the system, upstream from the heat generator, to intercept the impurities present in the circuit before they reach the heat generator itself. When installing Dirtstop EASY in a new heating system, pre-flush the pipes to free them from any dirt and debris.
Its cleaning does not require disassembly; the operation is very simple because just open the ball valve located in the lower part and let the residues flow into a container to be placed in the lower part.
The Dirtstop EASY dirt separator is specially designed to be installed without further modifications to the component. Just open the package, screw on the cap, swivel fitting and shut-off valve to be able to install the dirt separator in any position with a guarantee of maximum effectiveness.
DIMENSIONS
Length: 165 mm – Width: 70 mm – Height: 155 mm - Connections: ¾” F x ¾” M
WARRANTY
The guarantee is the official IVAR one and has a duration of 2 years .
